ARCFOX Alpha S

Reference FOB Price

US $31,421.00 / Piece | 1 Piece (Min. Order)

Color:	Grey / White / Black
Brand Name:	ARCFOX
Max Speed:	180 Km/h
LWH(mm):	4930 * 1940 * 1599
Body Type:	Sedan

Contact Us

For more detailed information including pricing, customization, and shipping.

+86 137 1706 4418 Inquiry Now

Product Detail Specification Packing & Delivery Company Profile FAQ

	2023 Advance Edition	2022 525S 175kW	2022 525S+175kW	2022 708S 175kW	2022 708S+175kW	2022 603H	2022 603H Little Prince Co branded Edition
Basic parameters
manufacturer	BAIC New Energy	BAIC New Energy	BAIC New Energy	BAIC New Energy	BAIC New Energy	BAIC New Energy	BAIC New Energy
level	Medium to large vehicles	Medium to large vehicles	Medium to large vehicles	Medium to large vehicles	Medium to large vehicles	Medium to large vehicles	Medium to large vehicles
Energy type	Pure electric	Pure electric	Pure electric	Pure electric	Pure electric	Pure electric	Pure electric
Listing time	2023.05	2022.08	2022.08	2022.08	2022.08	2022.08	2022.08
NEDC pure electric range (km)	-	525	525	-	-	603	603
CLTC pure electric range (km)	500	-	-	708	708	-	-
Fast charging time (hours)	0.25	0.5	0.5	0.6	0.6	0.6	0.6
Slow charging time (hours)	13	11.5	11.5	15.5	15.5	15.5	15.5
Fast charging percentage	80	80	80	80	80	80	80
Maximum power (KW)	473	175	175	175	175	320	320
Maximum torque (N · m)	655	360	360	360	360	720	720
Electric motor (Ps)	643	238	238	238	238	435	435
Length * Width * Height (mm)	4980 * 1960 * 1599	4930 * 1940 * 1599	4930 * 1940 * 1599	4930 * 1940 * 1599	4930 * 1940 * 1599	4930 * 1940 * 1599	4930 * 1940 * 1599
Maximum speed (km/h)	200	180	180	180	180	180	180
Official 0-100km/h acceleration (s)	3.5	7.7	7.7	8.3	8.3	4.2	4.2
Equivalent fuel consumption of electric energy (L/100km)	-	1.67	1.67	1.74	1.74	1.93	-
Vehicle warranty	Five years or 200000 kilometers	Five years or 200000 kilometers	Five years or 200000 kilometers	Five years or 200000 kilometers	Five years or 200000 kilometers	Five years or 200000 kilometers	Five years or 200000 kilometers
body
Length (mm)	4980	4930	4930	4930	4930	4930	4930
Width (mm)	1960	1940	1940	1940	1940	1940	1940
Height (mm)	1599	1599	1599	1599	1599	1599	1599
Wheelbase (mm)	2915	2915	2915	2915	2915	2915	2915
Front track width (mm)	1660	1660	1660	1660	1660	1660	1660
Rear wheelbase (mm)	1640	1640	1640	1640	1640	1640	1640
Trunk capacity (L)	550-1290	560-1300	560-1300	560-1300	560-1300	560-1300	560-1300
Curb weight (kg)	2115	1900	1940	2030	2078	2245	-
Maximum fully loaded mass (kg)	2565	2350	2390	2480	2528	2695	-
motor
Motor type	Front AC/Asynchronous Rear Permanent Magnet/Synchronous	Permanent magnet/synchronous	Permanent magnet/synchronous	Permanent magnet/synchronous	Permanent magnet/synchronous	Permanent magnet/synchronous	Permanent magnet/synchronous
Total power of electric motor (KW)	473	175	175	175	175	320	320
Total power of electric motor (Ps)	643	238	238	238	238	435	435
Total torque of electric motor (N · m)	655	360	360	360	360	720	720
Maximum power of front motor (KW)	221	175	175	175	175	160	160
Maximum torque of front motor (N · m)	285	360	360	360	360	360	360
Maximum power of rear motor (KW)	252	-	-	-	-	160	160
Maximum torque of rear motor (N · m)	370	-	-	-	-	360	360
Number of drive motors	Dual motor	Single motor	Single motor	Single motor	Single motor	Dual motor	Dual motor
Motor layout	Front+Rear	Front	Front	Front	Front	Front+Rear	Front+Rear
Battery type	Ternary lithium battery	Ternary lithium battery	Ternary lithium battery	Ternary lithium battery	Ternary lithium battery	Ternary lithium battery	Ternary lithium battery
Battery cooling method	Liquid cooling	Liquid cooling	Liquid cooling	Liquid cooling	Liquid cooling	Liquid cooling	Liquid cooling
NEDC pure electric range (km)	-	525	525	-	-	603	603
CLTC pure electric range (km)	500	-	-	708	708	-	-
Battery energy (kWh)	74.5	65.6	65.6	94.5	94.5	93.6	93.6
Battery energy density (Wh/kg)	181	183.3	183.3	188.8	188.8	191.72	191.72
Power consumption per 100 kilometers (kWh/100km)	16.6	14.8	14.8	15.4	15.4	17.1	17.1
Battery pack warranty	The first car owner has an unlimited number of years/mileage (the liability exemption clause shall be subject to official regulations)	Eight years or 160000 kilometers	The first car owner has an unlimited number of years/mileage (the liability exemption clause shall be subject to official regulations)	Eight years or 160000 kilometers	The first car owner has an unlimited number of years/mileage (the liability exemption clause shall be subject to official regulations)	The first car owner has an unlimited number of years/mileage (the liability exemption clause shall be subject to official regulations)	The first car owner has an unlimited number of years/mileage (the liability exemption clause shall be subject to official regulations)
Fast charging function	support	support	support	support	support	support	support
Fast charging time (hours)	0.25	0.5	0.5	0.6	0.6	0.6	0.6
Slow charging time (hours)	13	11.5	11.5	15.5	15.5	15.5	15.5
Fast charging capacity (%)	80	80	80	80	80	80	80

Company Profile

GemelCar is a Chinese automobile trading company. lt's main products include: Automobiles, new energy vehicles, EV Cars, used car and auto parts, etc. It's products have been successfully sold to more than 70 countries and regions around the world. At the same time, GemelCar have established long-term strategic cooperation partnership with BYD, XPENG, NIO, Lixiang, Arcfox, HOZON, etc.

GemelCar committed to be the most professional Automobile Exporter in China.

What's your minimum Order quantity?

1 unit.
What kind of payment terms can be acceptable?

We're flexible for payment terms, including T/T, L/C, D/P, O/A and of course Cash.
What brands do you have?

GemelCar have established long-term strategic cooperation partnership with BYD, XPENG, NIO, Lixiang, Arcfox, HOZON,, etc. We are dealing with the most popular vehicles Made in China.
What is the ordering process?

1). Select your preferred car, confirmed the price and delivery term with our sales.
2). Hesu create Alibaba Trade Assurance order or prepare the PI with bank details.
3). Make deposit payment or issue L/C.
4). After deposit payment confirmed, Hesu get the vehicle/s ready.
5). Balance payment should be done before goods delivery.
What kind of trade terms available from your side?

We can deal by EXW, FCA, FOB, CFR, DAP, CIF, DDP. etc.
How about the delivery time?

The delivery time will be various by different cars, please contact with our sales/online service for details.
How to guarantee the trade safety if I made the payment?

We can deal on Alibaba by trade assurance order, so that both parties can be guaranteed.
What’s your supportive policy for distributors in overseas market?

We support in many aspects including marketing, promotion, product development/improvements, service training, advertising, etc.
If I have other questions, whom should I ask?

You can contact us here online, our sales will respond within 10 mins.
